BERGQUIST GAP PAD TGP A2600return


    Features and Benefits

    1.Thermal conductivity: 2.6 W/m-K

    2.Fiberglass-reinforced for puncture,  shear and tear resistance

    3. Reduced tack on one side to aid in  application assembly

    4. Electrically isolating


Data download



BERGQUIST GAP PAD TGP A2600 is  a thermally conductive, filled-polymer  laminate, supplied on a reinforcing

mesh for added electrical isolation,  easy material handling and enhanced  puncture, shear and tear resistance.

BERGQUIST GAP PAD A3000 has a  reinforcement layer on the dark gold side  of the material that assists

in burn-in and  rework processes while the light gold  and soft side of the material allows for  added compliance.


BERGQUIST GAP PAD A3000 Typical Applications Include:

1. Computers and peripherals

2. Heat pipe assemblies

3.CD-ROM and DVD cooling

4. Areas where heat needs to be  transferred to a frame, chassis or other  type of heat spreader

5.Telecommunications • Memory modules

6. Between CPU and heat spreader


BERGQUIST GAP PAD TGP A2600 Configurations Available:

1.Sheet form, die-cut parts and roll form (converted or unconverted)
